SUN2000-20KTL-M3
The Huawei SUN2000-20KTL-M3 is a 20kW three-phase inverter designed for commercial and industrial PV systems, with a maximum efficiency of 97.6% and support for up to 8 MPPTs. It features Type II surge arresters for both AC and DC, integrated monitoring, anti-islanding protection, and a fuse-free, transformerless design suitable for grid connection at voltages of 120/208V or 127/220V (sources: documents 2, 4, 6, 7).
Images
Pros and cons
Pros
Strengths called out by generated product content.
- Maximum efficiency of 97.6%
- Supports up to 30,000 W of PV input power across 8 MPPT trackers
- Features four MPPTs for optimal panel adaptation
- Designed for commercial and industrial PV systems
- Integrated PID recovery function to recover module degradation
- Fault detection technology on the DC side as a standard feature
- Supports both 120Vac and 208Vac output voltages
- Rated AC output of 20kW
Cons
Tradeoffs and constraints to review before choosing.
- Maximum DC input voltage of 800 V, which may limit some configurations
- Requires qualified technicians for installation and operation
- Potential for improper operation if input voltage exceeds the operating range
Notes
Context that does not fit neatly as a pro or con.
- Some discussions mention oversizing inverters or choosing larger units for future expansion
Electrical Specifications
Performance
- Efficiency
- 97.6 %4
