Sunny Central UP

The SMA Sunny Central UP is a high-capacity central inverter designed for large-scale PV and battery systems, with system voltages of 1500 V DC and outputs up to 4600 kVA. It features efficient cooling (OptiCool), robust outdoor suitability, and flexible grid compliance, supporting DC-coupled storage and optional customer equipment space. Long service life of 25 years and compatibility with various grid requirements are emphasized (sources: documents 2, 3, 4, 9, 10, 11, 12, 14, 16, 17, 18).

Images

Sunny Central UP
img_tag
Sunny Central UP
img_tag

Pros and cons

Pros

Strengths called out by generated product content.

  • SMA inverters are considered reliable and have a long lifespan.
  • They are suitable for large-scale and residential installations with limited shading.
  • Modular components in SMA inverters are easy to replace, aiding longevity.
  • SMA inverters can link multiple systems and loads, enabling mini grid creation.
  • They have a good reputation for durability, with some units over 15 years old still operational.
  • SMA Sunny Central Storage UP-S supports high-performance, scalable storage projects with advanced technology.
  • SMA inverters are designed in Germany and built in China, with some models offering multiple MPPTs.

Cons

Tradeoffs and constraints to review before choosing.

  • SMA inverters may lack panel-level monitoring features.
  • Older SMA models and Sunny Boy units have experienced internal issues and obsolescence.
  • Replacement parts and customer support have become difficult to obtain in some regions.
  • Some SMA inverters have been reported to fail due to design or temperature issues, especially in hot environments.
  • The newer SMA hybrid inverters' pricing and availability are uncertain.

Notes

Context that does not fit neatly as a pro or con.

  • SMA inverters used to include emergency power options and grid-forming capabilities.
  • They can be integrated with custom monitoring via Modbus TCP for real-time data.
  • Inverters like Sunny Island can charge batteries during grid outages, depending on system setup.
  • Some users compare SMA to other brands like Fronius and SolarEdge, noting differences in features and price.

Electrical Specifications

Max Output Power
4,600 W1
Max Input Voltage
1,500 V1
MPPT Tracking
4 count1
Input Voltage Range
880 to 1325 V / 1050 V2

Power Ratings

Max Input Power
4,8003
Rated Power
4,600 kVA1
Max Apparent Output Power
4,6001
Night Self Consumption
2,000 W2
Self Consumption Max
4,800 W3
Self Consumption Standby
370 W3

Electrical Input

Start Up Voltage
1,030 V3

Performance

Efficiency
98.62
Operating Temperature Range
−25°C to 60°C3

Electrical Output

Rated Grid Voltage
1,500 V3
Rated Grid Frequency
502

Physical Characteristics

Weight
3,400 kg3
IP Rating
NEMA 3R3
Physical Dimensions
2780 / 2318 / 1588 mm3

Connectivity

Communication Interfaces
Ethernet, Modbus Master, Modbus Slave1

Efficiency

Efficiency Max
98.82
Mppt Efficiency
99.2 %3

Features

Features
Conforms to all known grid requirements worldwide, Connection area for customer equipment, DC-coupled battery storage compatibility, DC-coupled storage with optional charging from grid, High efficiency, Improved DC connection area, Integrated voltage, Integrated voltage support for internal and external loads, Intelligent air cooling system OptiCool, Long service life (25 years), More power per cubic meter, Suitable for outdoor use, Suitable for outdoor use in all climatic ambient conditions1

Protection Features

DC Reverse Polarity Protection
Yes3
Short Circuit Protection
Yes3
Output Over Current Protection
Yes3
Output Over Voltage Protection
Yes3
Insulation Resistance Monitoring
Yes3
Residual Current Detection
Yes2
Surge Protection
Yes2
Grid Monitoring
Yes2
Islanding Protection
Yes2
Temperature Protection
Yes2

Physical Dimensions

Physical Length
2,815 cm3
Physical Width
109.4 cm2
Physical Height
2,318 cm3
Type Phase Series Fro P Length
150 cm2
Type Phase Series Fro P Width
109.4 cm2
Type Phase Series Fro P Depth
62.5 cm2
Dimensions Length
158.8 cm2
Dimensions Width
110.8 cm2
Dimensions Height
91.3 cm2

Environmental

Max Operation Altitude
1,000 m3
Ingress Protection
54 IP2
Noise Emission
63 dba3

General

Topology
outdoor2
Designed Lifetime
25 years2
